AUTO CLAMP

TN SERIES

  • CHEON GI’s TN AUTO-CLAMP is one of the

components for Q.D.C. SYSTEM.

  • This type is air drive and rod swing.
  • Since the power output of the Air Cylinder is

increased by the Electric power.

While clamping, the group rod has high

pulling and supporting power.

  • Especially, since TN-B(spring built-in)type for

upper part has the strong built-in spring in

the Air Cylinder, sufficient power for Die does

not fall down even during the pause of the

press machine.

  • Since the standard model has the indicator of

clamping and unclamping, the secure INTER-

LOCK can be formed and the maintenance of

the function of each part is simple.
